ABOUT CONTAINERIZED SUBSTATION
Containerized substation is a complete power supply and distribution system including the transformer, HV, LV compartments and other electrical equipment.
The substation is composed of auxiliary equipment, air conditioning, lighting, fire protection, safety, imaging and other equipment. The decorative materials are made of fire-resistant and waterproof materials. Insulation materials can be added between the decorative materials and the bulkheads to prevent sunlight exposure and ensure the insulation function inside the prefabricated cabin.
The lighting and air conditioning inside the substation can be selected according to different requirements. For economic efficiency, industrial air conditioning and exhaust systems are installed in the prefabricated cabin, which can adjust the operating environment in real-time. Due to the current unmanned mode, safety, image, image monitoring, and fire alarm systems must be installed in the substation. The wiring method can be determined based on the equipment.
MAJOR FEATURES FOR CONTAINERIZED SUBSTATION
• Lower compared with the weight of the concrete kiosk
• Lower transport and handling costs compared with the concrete kiosk
• Use of transformer - dry / oil, components from various world manufacturers
• Repeated use saves costs compared to conventional transformer stations
• Use in all climatic conditions
• Storage in a place without demanding landscaping
DESIGN DETAILS FOR CONTAINERIZED SUBSTATION
• In accordance with IEC standard and International Standards
• Prefabricated substation contains MV and LV switchgear panels with distribution transformer to provide comprehensive solution
• Equipped with high quality MV and LV equipment
• Reduce inter-equipment cabling cost
• Monitoring & Control as standard feature
• Protect operating personnel against atmosphere
• MV Switchgear, LV switchgear and Distribution transformer are segregated by sheet steel partition
• Provides high degree of protection against ingress of solid foreign objects
• Fitted with mandatory safety interlocks
• Complete sheet steel housing is readily earthed
FITTINGS & ACCESSORIES
• Accessory electrical equipment
• Monitoring & Control for MV and LV equipment
• Utility measurement box (internal or external)
• Fixed PFC
• Automatic PFC (optional)
• UPS (Uninterruptable Power Supply)
• Fire detection and extinguishing (optional)
• Internal accessories and auxiliary installations
• Lighting installation with electric switch
• Interlocked socket
• HVAC (optional)
• External cabinet accessories
• Flashing warning light (IP55)
• Emergency pushbutton under glass
